Product Information


CW2004 Car Wash Series - Triplex Plunger Pump

General Pump CW series pumps are especially constructed to handle the rigorous duty cycles, high temperatures and chemicals associated with car wash applications.
CW series pumps are backed by a 5 year warranty


• The preferred pump frame in the car wash self-service industry

• Forged brass manifold with an exclusive lifetime warranty

• Large-capacity, die-cast, anodized aluminum oil-bath crankcase

• Over-sized connecting rods for maximum life

• Heavy-duty tapered roller bearing.

• Solid ceramic plungers with continuously lubricated packings

• Unitized stainless steel inlet and discharge valves

• Available in left-handed “L” version
Max. Discharge Pressure

2000 PSI
Maximum Pump Speed

1750 RPM
Maximum Inlet Pressure

125 PSI
Bore

.787 in. / 20 mm
Stroke

.630 in. / 16 mm
Crankcase Oil Capacity

33.8 oz.
Maximum Fluid Temperature
165°F
Inlet Port Thread

1/2-14 BSPP-F
Discharge Port Thread

3/8-19 BSPP-F
Shaft Diameter

1.378 in. / 35 mm
Weight

30 lbs.
Dimensions

11.4” x 9.2” x 7.2”
Replacement Parts
Valves - Kit 1
Piston Oil Seal - Kit 2
Packings - Kit 969
Packings with Brass - Kit 9101A
Pistons - 47040409
Valve Caps - Kit 4
Piston Bolts - Kit 6
Crank Oil Seal - Kit 3
Price
$955.99
Taxes and shipping calculated at checkout
In stock and ready for shipping
