CW2040 PUMP by GENERAL PUMP (3107)
CW2040 PUMP by GENERAL PUMP (3107)
CW2040 PUMP by GENERAL PUMP (3107)
CW2040 PUMP by GENERAL PUMP (3107)

CW2040 PUMP by GENERAL PUMP (3107)

Product Information

General Pump CW series pumps are especially constructed to handle the rigorous duty cycles, high temperatures and chemicals associated with car wash applications.
CW series pumps are backed by a 5 year warranty
  • The preferred pump frame in the car wash self-service industry
  • Dual crankshaft for convenience
  • Forged brass manifold with an exclusive lifetime warranty
  • Large-capacity, die-cast, anodized aluminum oil-bath crankcase
  • Over-sized connecting rods for maximum life
  • Heavy-duty tapered roller bearing
  • Solid ceramic plungers with continuously lubricated packings
  • Unitized stainless steel inlet and discharge valves
Maximum Volume
5.0 gpm @ 1500 psi, 1250 rpm
Max. Discharge Pressure
1500 psi @ 3.0 gpm, 750 rpm
Maximum Pump Speed
1250 rpm @ 5.0 gpm, 2000 psi
Maximum Inlet Pressure
125 psi
Bore
.787 in / 20 mm
Stroke
.630 in / 16 mm
Crankcase Oil Capacity
33.8 oz
Maximum Fluid Temperature
165°F
Inlet Port Thread
1/2-14 BSPP-F
Discharge Port Thread
3/8-19 BSPP-F
Shaft Diameter
.945 in / 24 mm Dual Shaft
Weight
30 lbs
Dimensions
11.4 x 10.8 x 7.2 in

Replacement Parts Available

(1416) Valves - Kit 1

(1417) Piston Oil Seal - Kit 2

(5096) Packing's - Kit 969

(3980) Packing's with Brass - Kit 9101A

(1622) Pistons - 47040409

(1614) Valve Caps - Kit 4

(1610) Piston Bolts - Kit 6

(1601) Crank Oil Seal - Kit 3

Pump Specs

Pump Troubleshooting

Price
$980.99
Taxes and shipping calculated at checkout
In stock and ready for shipping
