CW3040 PUMP by GENERAL PUMP (3108)

Pump Model CW3040

Maximum Volume 5.0 GPM

Maximum Discharge Pressure 3000 PSI

Maximum Pump Speed 1250 RPM

Maximum Inlet Pressure 125 PSI

Maximum Inlet Vacuum 9 ft. water (7.9 in. Hg)

Plunger Bore .787 in. / 20 mm

Plunger Stroke .630 in. / 16 mm

Crankcase Oil Capacity 40.6 oz.

Maximum Fluid Temperature 165o F

Inlet Port Thread 1/2-14 BSP-F

Discharge Port Thread 3/8-19 BSP-F

Shaft Diameter .945 in. / 24 mm

Weight 32 lbs.

Dimensions 12.2” x 9.2” x 7.2”

Replacement Parts Available

(1416) Valves - Kit 1

(1417) Piston Oil Seal - Kit 2

(5096) Packing's - Kit 969

(3980) Packing's with Brass - Kit 9101A

(1622) Pistons - 47040409

(1614) Valve Caps - Kit 4

(1610) Piston Bolts - Kit 6

(1601) Crank Oil Seal - Kit 3
