Product Information

The EZ2536E pump by General Pump features:

Max. GPM 3.6
Max. PSI 2500
RPM 1750
Bore .708″ – 18mm
Stroke .433″ – 11mm
Required HP 6.2 EBHP
Shipping Weight 19 lbs
Comes with NEMA/184TC Flange



Hollow Shaft – General Pump EZ 44 Series Specs:
Max. Inlet Pressure 125 PSI
Max. Fluid Temperature 165 Degrees Fahrenheit
Inlet Port Thread 1/2″ – 14 BSP-F
Discharge Port Thread 3/8″ – 19 BSP-F
Shaft Diameter 1/1/8″ (1.125″)
Pump Dimensions 8.8″ x 8.8″ x 6.3″
Crankcase Oil Capacity 14.0 oz (use GP Series 100 Oil)



Hollow Shaft – General Pump EZ 44 Series Features:

  • Triplex Plunger Pump.
  • Forged brass manifold with exclusive lifetime warranty.
  • Solid ceramic plunger design
  • Die/cast, anodized aluminum oil bath crankcase
  • Unitized stainless steel inlet and discharge valves

Replacement Parts Available

Valves - Kit 123

Piston Oil Seal - Kit 23

Packing's - Kit 127

Packing's with Brass - Kit 131

Pistons - 44040109

Valve Caps - Kit 124

Piston Bolts - 99317500

Crank Oil Seal - 90169000

Price
$669.75
Taxes and shipping calculated at checkout
Out of stock
