EZ4035G34 PUMP by GENERAL PUMP (6586)

Features include:

• Standard SAE J609 gasoline mounting flange for up to 13 hp engines
• Forged brass manifold with an exclusive lifetime warranty and 3:1 hydrostatic rating
• Die-cast, anodized aluminum oil-bath crankcase
• Innovative one-piece plunger design to eliminate water entering crankcase
• Premium roller bearing
• 5% reduction in crankcase load compared to standard 3,000 PSI, 15mm pumps
• Unitized stainless steel inlet and discharge valves
• Available in “L” left-handed versions

Specifications:

• Maximum Volume: 3.5 GPM
• Maximum Discharge Pressure: 4000 PSI
• Maximum Pump Speed: 3400 RPM
• Maximum Inlet Pressure: 125 PSI
• Maximum Inlet Vacuum: 3ft. Water (2.6 in Hg)
• Plunger Bore: .512 in. / 13 mm
• Plunger Stroke: .433 in. / 11 mm
• Crankcase Oil Capacity: 14.0 oz.
• Maximum Fluid Temperature: 165 F
• Inlet Port Thread: 1/2-14 BSPP-F
• Discharge Port Thread: 3/8-19 BSPP-F
• Shaft Diameter: 1.0 in. / 25.4 mm
• Weight: 20 lbs.
• Dimensions: 8.8" x 9.7" x 6.5"
