TX1510G8UIA PUMP by GENERAL PUMP (6544)

The TX1510G8UIA pump by General Pump is

• High Quality Replacement
• Consumer grade is ideal for all general cleaning applications
• Direct drive for convenience and durability
• Triplex Plunger Pump with Solid White Ceramic Plungers
• Runs cooler and lasts longer than axial pumps
• Next generation packings for exceptional seal life
• Built In Pressure Trapping Unloader and Injector
• Adjustable pressure is handy and versatile
• Injector allows use of any pressure washer safe detergent
• Oversized Connecting Rods
• Can handle up to 3400 RPM
• 1" Hollow Shaft And J609-b Motor Flange
• Inlet port thread 1/2"*14 BSP*F
• Discharge port thread 3/8"-19 BSP-F
• Maximum fluid temperature 160 degrees F
• Bore .591 in. / 15mm, stroke .394 in. / 10mm
• 14-ounce oil capacity

Pump Specifications

Pump Service Instructions
