XW-M26.23N PUMP by AR PUMPS (5333)

Product Information

The Annovi Reverberi XWM2623N, N version 24mm solid shaft triplex pump is ready for direct or pulley driving. This pump is manufactured with a brass pump head suitable for a wide range of conditions. The XWM2623N can produce up to 3600 Max PSI, 6.87 Max GPM, and is designed to operate at 1450 RPM. Constructed with frictionless aluminum connecting rods and ceramic pistons, the XWM2623N weighs in at 34 lbs and delivers the performance you demand.

Max GPM	6.87
Max L/Min	26
Max PSI	3600
MaxBar	250
Power EBHP	17
Bore Dia mm	20
Stroke mm	19.8
Crankshaft ID Stamp	1
Inlet	3/4" F
Outlet	3/8" F
Max Temp	140° F
Oil Capacity (oz)	32
Weight	34
RPM	1450
Shaft Size	24mm
Shaft Version	N
Shaft Type	Solid
